• The easy installation to any beam makes it suitable for fixing to any moving hoist, pulleys and loads.
  • It can be adjusted quickly to the beam width by turning the main spindle.
  • Safety is ensured by the special locking lever.
  • The spindle and snap-pin stops are galvanized to protect against corrosion.
  • Conforms to CE safety standard

Product Specification
ModelCapacity (kg)Welding Size a (mm)Dimensions
LxB

L1L2L3L4L5Weight
WH101000490x251724676220.4
WH3030005130x3524298105281.25
WH5050005160x45303710132472.35
WH8080007170x50404710138503.6
